//! Flex container — the composition primitive.
//!
//! Holds a [`LayoutStyle`] and a list of children, each tagged with a
//! [`Dimension`] for its main-axis sizing. Delegates rect assignment to the
//! [`solve`](crate::layout::solve) flexbox solver, then renders each
//! child into its rect through a clipped child surface. Nesting `Flex`es is how
//! every screen is built.
use ratatui_core::layout::Rect;
use ratatui_core::style::Style;
use crate::geometry::Size;
use crate::layout::{Dimension, Item, LayoutStyle, solve};
use crate::surface::Surface;
use crate::view::{Element, RenderCtx, View};
struct Child {
view: Element,
dimension: Dimension,
}
/// A flexbox container of child views.
///
/// # Example
///
/// ```
/// use tuika::prelude::*;
/// use tuika::testing::{grid, render};
///
/// // A row of two fixed-width cells, laid left to right.
/// let view = Flex::row()
/// .fixed(3, element(Text::raw("abc")))
/// .fixed(3, element(Text::raw("xyz")));
///
/// let buffer = render(&view, 6, 1, &Theme::default());
/// assert_eq!(grid(&buffer), "abcxyz");
/// ```
///
///
pub struct Flex {
style: LayoutStyle,
children: Vec<Child>,
background: Option<Style>,
}
impl Flex {
/// An empty flex container with the given layout style.
pub fn new(style: LayoutStyle) -> Self {
Self {
style,
children: Vec::new(),
background: None,
}
}
/// An empty container laying children left-to-right along the horizontal axis.
pub fn row() -> Self {
Self::new(LayoutStyle::row())
}
/// An empty container stacking children top-to-bottom along the vertical axis.
pub fn column() -> Self {
Self::new(LayoutStyle::column())
}
/// Fill the container area with `style` before drawing children.
pub fn background(mut self, style: Style) -> Self {
self.background = Some(style);
self
}
/// Set the gap between children (passthrough to the layout style).
pub fn gap(mut self, gap: u16) -> Self {
self.style.gap = gap;
self
}
/// Set padding inside the container (passthrough to the layout style).
pub fn padding(mut self, padding: crate::geometry::Padding) -> Self {
self.style.padding = padding;
self
}
/// Set cross-axis alignment (passthrough to the layout style).
pub fn align(mut self, align: crate::layout::Align) -> Self {
self.style.align_items = align;
self
}
/// Set main-axis distribution (passthrough to the layout style).
pub fn justify(mut self, justify: crate::layout::Justify) -> Self {
self.style.justify = justify;
self
}
/// Add a child with an explicit main-axis dimension.
pub fn child(mut self, dimension: Dimension, view: Element) -> Self {
self.children.push(Child { view, dimension });
self
}
/// Add an auto-sized child (sizes to its measured content).
pub fn auto(self, view: Element) -> Self {
self.child(Dimension::Auto, view)
}
/// Add a flexible child that grows to share leftover space.
pub fn grow(self, weight: u16, view: Element) -> Self {
self.child(Dimension::Flex(weight), view)
}
/// Add a fixed-size child.
pub fn fixed(self, cells: u16, view: Element) -> Self {
self.child(Dimension::Fixed(cells), view)
}
fn items(&self, available: Size) -> Vec<Item> {
self.children
.iter()
.map(|c| Item::new(c.dimension, c.view.measure(available)))
.collect()
}
/// Resolve the child rects this container would assign inside `area`,
/// without painting anything.
///
/// This is the same measure-then-[`solve`] pass `render` runs, exposed so a
/// host can compute layout ahead of (or instead of) a render — to clamp a
/// scroll offset to a pane's real height, hit-test a click against child
/// rects, or decide what fits before drawing. The returned `Vec` has one
/// rect per child, in insertion order.
///
/// ```
/// use tuika::prelude::*;
/// use ratatui_core::layout::Rect;
///
/// let flex = Flex::row()
/// .fixed(4, element(Text::raw("abcd")))
/// .grow(1, element(Text::raw("rest")));
/// let rects = flex.solve(Rect::new(0, 0, 10, 1));
/// assert_eq!(rects.len(), 2);
/// assert_eq!(rects[0], Rect::new(0, 0, 4, 1));
/// assert_eq!(rects[1], Rect::new(4, 0, 6, 1)); // grows into the leftover
/// ```
pub fn solve(&self, area: Rect) -> Vec<Rect> {
solve(area, &self.style, &self.items(Size::from(area)))
}
}
impl View for Flex {
fn measure(&self, available: Size) -> Size {
// Sum children on the main axis, max on the cross axis, plus gaps and
// padding. Used when this Flex is itself an Auto child.
let axis = self.style.direction.axis();
let inner = self
.style
.padding
.inner(Rect::new(0, 0, available.width, available.height));
let inner_avail = Size::from(inner);
let mut main_total: u16 = 0;
let mut cross_max: u16 = 0;
for (i, c) in self.children.iter().enumerate() {
let sz = c.view.measure(inner_avail);
main_total = main_total.saturating_add(axis.main(sz));
if i > 0 {
main_total = main_total.saturating_add(self.style.gap);
}
cross_max = cross_max.max(axis.cross(sz));
}
let content = axis.size(main_total, cross_max);
Size::new(
content
.width
.saturating_add(self.style.padding.horizontal()),
content.height.saturating_add(self.style.padding.vertical()),
)
}
fn render(&self, area: Rect, surface: &mut Surface, ctx: &RenderCtx) {
if let Some(bg) = self.background {
let mut fill = surface.child(area);
fill.fill(bg);
}
let rects = self.solve(area);
for (child, rect) in self.children.iter().zip(rects) {
let mut child_surface = surface.child(rect);
child.view.render(rect, &mut child_surface, ctx);
}
}
}
#[cfg(test)]
mod tests {
use super::*;
use crate::components::Text;
use crate::probe::RectProbe;
use crate::style::Theme;
use crate::view::element;
#[test]
fn solve_matches_the_rects_render_paints_into() {
// Probe every child, render, then compare the painted rects to what the
// paint-free `solve` returns for the same area — they must be identical.
let area = Rect::new(0, 0, 20, 6);
let probes: Vec<RectProbe> = (0..3).map(|_| RectProbe::new()).collect();
let flex = Flex::column()
.fixed(1, probes[0].wrap(element(Text::raw("header"))))
.grow(1, probes[1].wrap(element(Text::raw("body"))))
.fixed(2, probes[2].wrap(element(Text::raw("footer"))));
let precomputed = flex.solve(area);
let _ = crate::testing::render(&flex, area.width, area.height, &Theme::default());
let painted: Vec<Rect> = probes.iter().map(|p| p.rect()).collect();
assert_eq!(
precomputed, painted,
"solve() must return exactly the rects render() paints into"
);
// And they are the expected column layout: 1-row header, grown body, 2-row footer.
assert_eq!(precomputed[0], Rect::new(0, 0, 20, 1));
assert_eq!(precomputed[1], Rect::new(0, 1, 20, 3));
assert_eq!(precomputed[2], Rect::new(0, 4, 20, 2));
}
#[test]
fn solve_of_empty_container_is_empty() {
let flex = Flex::row();
assert!(flex.solve(Rect::new(0, 0, 10, 3)).is_empty());
}
#[test]
fn crate_root_reexports_solver_primitives() {
// `solve` and `Item` are reachable from the crate root, not just
// `tuika::layout` — build a layout by hand without a Flex.
use crate::Size;
use crate::layout::{Dimension, Item, LayoutStyle, solve};
let items = [
Item::new(Dimension::Fixed(3), Size::new(3, 1)),
Item::new(Dimension::Flex(1), Size::new(0, 1)),
];
let rects = solve(Rect::new(0, 0, 10, 1), &LayoutStyle::row(), &items);
assert_eq!(rects[0], Rect::new(0, 0, 3, 1));
assert_eq!(rects[1], Rect::new(3, 0, 7, 1));
}
}
