ratada

A reusable ratatui widget toolkit for Rust terminal apps.

ratada provides the generic building blocks for a TUI over ratatui and crossterm: a terminal guard and event loop, modals, forms, text editing, pickers, tables, trees, a fuzzy finder, a help overlay, a command palette, footers and status bars, plus a framework-agnostic theming layer (colors, palette and glyphs) that maps onto ratatui styles.

Overview

• Driver – a Tui RAII terminal guard (raw mode + alternate screen) and a generic run loop over a Screen trait.
• Widgets – modals (confirm, confirm_default, input, input_wide, select, multi_select, number_input, message), forms, single- and multi-line text editing with a shared editor core, autocomplete, tables, trees, selectable lists, sectioned sidebars, tabs, pagers, gauges, spinners, toasts (timed, stacked, each box as tall as its wrapped message).
• Pickers – color, swatch, date, date-range, month, path (with an optional confinement root) and slider pickers.
• Overlays & chrome – a fuzzy help overlay, a command palette, box framing, header and status bars, and wrapping shortcut-hint footers.
• Markdown – a CommonMark renderer (headings, lists, task lists, code blocks, quotes, GFM tables/callouts, links) producing styled lines, plus a scrollable MarkdownView widget and a viewer modal.
• Theming – a Skin bundling a Palette (semantic colors) and Glyphs (Unicode/ASCII variants); framework-agnostic so a CLI can share it, with a single ratatui adapter in style. A theme names a few base colors and the rest is derived: border_focus follows border unless it is set, and an override on border alone drags it along, so a focused frame never sinks into its own border.
• Diagnostics – degraded conditions (a missing clipboard tool, an unreadable directory, an invalid color override, a failed terminal restore) are emitted through the log facade at warn/error; install a logger to surface them.

Usage

[dependencies]
ratada = "0.3"

Requires Rust 1.88 or newer (the crate uses let-chains).

Implement the Screen trait and hand it to run, which owns the draw/input loop inside a raw-mode Tui guard. The prelude re-exports the driver essentials:

use ratada::prelude::*;
use ratatui::{Frame, text::Line};
use crossterm::event::{KeyCode, KeyEvent};

struct App {
    count: u32,
}

impl Screen for App {
    type Error = std::io::Error;

    fn render(&self, frame: &mut Frame) {
        frame.render_widget(
            Line::from(format!("count: {}  (space +1, q quit)", self.count)),
            frame.area(),
        );
    }

    fn handle_key(&mut self, key: KeyEvent, _tui: &mut Tui) -> std::io::Result<Flow> {
        match key.code {
            KeyCode::Char('q') => Ok(Flow::Quit),
            KeyCode::Char(' ') => {
                self.count += 1;
                Ok(Flow::Continue)
            }
            _ => Ok(Flow::Continue),
        }
    }
}

fn main() -> std::io::Result<()> {
    let mut tui = Tui::new()?;
    run(&mut tui, &mut App { count: 0 })
}

Widgets that support the opt-in boxed style take a BoxDecor (caption in the top border, an automatic or fixed badge bottom-right), e.g. InputField::new("").max_len(40).boxed(BoxDecor::new().caption("Name")).

Documentation

• API reference on docs.rs – the authoritative, complete rustdoc (or cargo doc --open locally).
• CHANGELOG.md – release history (Keep a Changelog + SemVer).
• DEVELOPMENT.md – module layout, conventions and how to add a widget.
• CLAUDE.md – the binding style guide.

License

Licensed under the MIT License. See LICENSE.
