Lux Aurumque — Light and Gold. A minimal transient path tracer in Rust, rendering a small gilded room as a wavefront of light sweeps through it.

preview

Standard renderers compute the steady-state radiance arriving at a sensor — the equilibrium reached after light has bounced around forever. Transient rendering refuses that simplification. Light propagates at a finite speed, and every photon path has a definite duration equal to its total optical length divided by c. By binning each path's contribution into a histogram indexed by that duration, we render not a single image but a movie of light propagating through the scene, frame by picosecond.

Run the demo

Requirements: Rust 1.88+ (edition 2024), a C linker (build-essential on Debian/Ubuntu), ffmpeg for the final encode.

cargo run --release -p lux-aurumque
ffmpeg -framerate 30 -i frames/frame_%04d.png \
       -c:v libx264 -pix_fmt yuv420p -crf 18 lux-aurumque.mp4

Defaults (640×480, 256 spp, 475 time bins of 40 ps) take a few minutes on a modern laptop and need ~800 MB of RAM. Tune WIDTH, HEIGHT, SAMPLES, NUM_BINS, DT at the top of src/main.rs.

What you'll see

A Cornell-box-style room reskinned in aurum — cream floor / ceiling / back wall, deep copper left wall, antique amber right wall. On the floor: a polished gold sphere and a smaller satin-gold diffuse sphere. Near the ceiling sits a small emitter that fires a single 50 ps Gaussian pulse, warm-tinted to roughly 3000 K.

Direct light arrives first at frame ~98 — the source disc itself.
Specular highlight on the gold sphere a few frames later, as the wavefront catches the polished surface.
Diffuse satin-gold sphere illuminating with a measurable delay (cosine-weighted scatter, longer effective path).
Warm colour bleed onto the cream walls arriving later still — each bounce adds a centimetre or two of path length.
Late tails in the last frames where multi-bounce paths trickle in.

Library use

The crate re-exports SpectralBudget — the Faber–Krahn bound that refuses parameter combinations whose total path-length horizon would exceed 3 · T_1 for the bounded scene. The renderer enforces this at startup; combinations that violate the budget are refused with a structured error before any computation runs.

Architecture

src/
├── main.rs          entry: scene setup, tile-based parallel render, PNG writeout
├── transient.rs     time-binned framebuffer + time-aware path tracer
├── camera.rs        pinhole camera ray generation
├── hit.rs           HitRecord, Hittable trait, world list
├── sphere.rs        analytic sphere intersection
├── material.rs      Lambertian / Metal / DiffuseLight (pulse emitter)
├── ray.rs           Ray with cumulative path_length
├── scene.rs         Cornell-box scene setup
└── vec3.rs          Vec3 conveniences over glam

The single conceptual delta from a textbook path tracer (Ray Tracing in One Weekend and friends) lives in three places:

Ray::path_length — every ray carries the cumulative optical length of its history. Each bounce adds the segment length to the next ray's starting path_length.
trace_path deposit step — when a path terminates on an emitter, its contribution is deposited into a window of bins around t_arrival = path_length / c, weighted by the source's Gaussian temporal profile.
TransientFrame — a 3D (height × width × num_bins) buffer, saved out as a per-bin PNG stack.

Physics knobs

Constant	Default	Effect
`WIDTH × HEIGHT`	640×480	Resolution — memory scales as `W × H × NUM_BINS × 12 bytes`
`SAMPLES`	256	Paths per pixel
`DT`	40 ps	Time-bin width — smaller = sharper wavefronts
`NUM_BINS`	475	Time slices; `NUM_BINS × DT × c` is the path-length window
`PULSE_SIGMA`	50 ps	Gaussian pulse temporal width
`TILE_SIZE`	64	Render tile edge; controls peak memory
