# ComChan

ComChan is a Blazingly Fast Serial monitor for Embedded Systems and Serial Communication.

**Latest Version**: 0.1.6

## Installation

### From crates.io


> [!NOTE]
> `cargo install` NOW AVAILABLE

```bash
cargo install comchan

#Install the binary directly
cargo binstall comchan
```

After installing, check if it has been installed with

```bash
comchan --version
```

### From source

```bash
# Clone from GitHub
git clone git@github.com:Vaishnav-Sabari-Girish/ComChan.git

# Clone from Codeberg
git clone ssh://git@codeberg.org/Vaishnav-Sabari-Girish/ComChan.git
```

```bash
cd ComChan

cargo build --release

cargo run
```

# Documentation Link

Documentation Link : https://vaishnav.world/ComChan

## Common Commands

### Basic Serial Monitor

```bash
comchan -p <port> -r <baud_rate>

# OR

comchan --port <port> --baud <baud_rate>

```

### Verbose Mode

```bash
comchan -p <port> -r <baud_rate> -v

# OR

comchan --port <port> --baud <baud_rate> --verbose
```

### Log Mode

```bash
comchan -p <port> -r <baud_rate> -l <log_file_name>

# OR

comchan --port <port> --baud <baud_rate> --log <log_file_name>
```

For an example log file , get it [here](./test.log)

### Serial Plotter

```bash
comchan --port <port> --baud <baud_rate> --plot

# OR

comchan -p <port> -r <baud_rate> --plot
```


## Features

- [x] Read incoming Serial data from Serial ports
- [x] Write to Serial port i.e Send data to Serial device.
- [x] Basic logging.
- [ ] Write serial data to a file for later use (can be .txt , .csv and more)
- [x] Terminal based Serial Plotter (to be implemented with the `--plot` command)


### Legends

- [x] Implemented Features
- [ ] Yet to me implemented

# Examples

## "Hello World" Program

![GIF](./docs/src/videos/basic_serial_mon.gif)

## User Input

![User IP](./docs/src/videos/basic_user_input.gif)

## Serial Plotter

![Serial Plotter](./docs/src/videos/plotter.gif)


# Feedback Form

The Feedback form was created using Bashforms (Forms in the terminal itself).

To give you feedback, please type this on your terminal

```bash
ssh -t bashform.me f comchan
```
