# codebase-recall
> **High-performance CLI codebase context dumper for LLMs and AST-based code relation grapher.**
`codebase-recall` (`code-rcl`) is a command-line tool built with Rust 🦀 designed for two primary developer workflows:
1. **Context Bundling for LLMs:** Scan your directory structure and bundle your codebase—or a focused, dependency-aware slice of it—into a clean, well-structured Markdown document ready for LLMs (ChatGPT, Claude, Gemini, DeepSeek).
2. **Code Relation Graph & Architecture Visualization:** Parse ASTs across multiple languages (Rust, Go, JS/TS, Python, Java, Kotlin, Vue, Svelte) to discover definitions, imports, and cross-file calls. Visualize interactions in real-time in an interactive browser UI or export to self-contained HTML, Graphviz DOT, or JSON.
---
## Demo
---
## Key Features
### 📦 Codebase Context Dumper (`dump`)
- **Full & Targeted Dumps:**
- **Full Dump:** Pack the entire repository with directory trees and filtered source contents.
- **Targeted / Relation-Aware Dump (`-r / --relation`):** Provide a target symbol or file; `code-rcl` traverses the dependency graph up to `--depth <N>` and dumps *only* connected and relevant files—saving prompt tokens and eliminating hallucination noise.
- **Smart Filtering:**
- Automatically respects `.gitignore` rules and ignores hidden directories (`.git/`, `.cache/`, etc.).
- Skips binary files, media assets (`.png`, `.webp`, `.pdf`, etc.), lockfiles (`Cargo.lock`, `package-lock.json`, `pnpm-lock.yaml`, `bun.lockb`, etc.), minified bundles (`.min.js`, `.chunk.js`), and sensitive environment files (`.env*`).
- **Safe Dynamic Markdown Fencing:** Detects the maximum backtick streak in file contents and dynamically expands markdown fences (e.g. ` ```` ` or ` ````` `) to prevent nested markdown from breaking document formatting.
- **Size Limits & Path Normalization:** Configurable per-file size limit (default: 50 KB) and automated path separator normalization across OS platforms.
### 🕸️ Code Relation Graph (`graph` & `serve`)
- **Multi-Language AST Parsing:** Powered by tree-sitter for **Rust**, **Go**, **JavaScript/JSX**, **TypeScript/TSX**, **Python**, **Java**, **Kotlin**, and Single-File Components (**Vue**, **Svelte**).
- **Multi-Tier Resolution:** Tracks symbols (functions, structs, classes, enums, methods), imports, and call references across files with confidence scoring.
- **Incremental SQLite Caching:** Stores file hashes (Blake3) and AST entities in `.code-rcl/cache.db`. Re-runs only parse files modified since the last sync.
- **Interactive Browser Viewer (`serve`):**
- Instant local visualization powered by vendored d3-force simulation (smooth zoom, pan, and drag).
- Toggle edge kinds (`imports`, `calls`, `references`).
- Interactive search filtering, node isolation, cluster expansion/collapsing, and press-and-hold node spotlighting.
- Interactive BFS depth adjuster directly inside the web UI.
- **Zero Background Footprint:** Uses a lightweight EventSource heartbeat; the local server automatically terminates when you close your browser tab.
- **Export Formats (`graph`):** Standalone zero-dependency HTML, Graphviz `.dot`, and structured JSON (`version: 2`).
---
## Installation
### Prebuilt Binaries
#### macOS / Linux (Shell Script)
```sh
#### Windows (PowerShell)
```powershell
### Install via Cargo (crates.io)
Ensure you have Rust and Cargo installed:
```bash
cargo install codebase-recall
```
### Build from Source
```bash
git clone https://github.com/BknOrg/codebase-recall.git
cd codebase-recall
cargo build --release
cargo install --path .
```
The compiled binary is available as `code-rcl`.
---
## Subcommands Overview
`code-rcl` is organized into subcommands:
| `code-rcl dump` | Bundle the codebase (or a symbol's neighborhood) into a single Markdown file for LLM context. |
| `code-rcl digest` | Generate an architecture outline and public API signature digest without function bodies. |
| `code-rcl impact` | Analyze blast radius and downstream/upstream callers affected by modifying a symbol. |
| `code-rcl init` | Initialize `.code-rcl/` (SQLite cache DB + `config.toml`) and ensure it is in `.gitignore`. |
| `code-rcl sync` | Incrementally parse changed source files into the graph cache. |
| `code-rcl graph` | Auto-sync, then export the relation graph to file(s) (`html`, `json`, `dot`). |
| `code-rcl serve` | Auto-sync, then host an interactive relation graph in the browser; exits when the tab closes. |
| `code-rcl mcp` | Run Model Context Protocol (MCP) server over stdio for AI agent integration. |
| `code-rcl setup` | Self-install AI agent skill and auto-configure MCP servers (Gemini/Antigravity, Claude Code). |
> **Interactive Help:** You can view parameter options and real usage examples for any command with `code-rcl <cmd> help` (e.g. `code-rcl dump help`, `code-rcl digest help`).
---
## Usage — `dump` (LLM Context Generator)
### 1. Standard Full Dump
Scan the repository and produce a comprehensive `codebase-context.md`:
```bash
# Scan current directory -> codebase-context.md
code-rcl dump
# Scan specific project directory and specify output filename
code-rcl dump ./path/to/project -o context.md
# Increase per-file size limit to 100 KB
code-rcl dump . --max-size-kb 100 -o full-context.md
```
### 2. Relation-Aware / Targeted Dump
When working with large codebases, dumping everything can exceed token context windows or degrade LLM reasoning. Use `--relation` (`-r`) to extract only the target file/symbol and its connected dependency neighborhood:
```bash
# Dump only files connected to `build_graph` within 2 degrees of relationship
code-rcl dump -r build_graph
# Dump files connected to a specific module/file with a custom depth of 3
code-rcl dump -r src/commands/dump.rs --depth 3 -o dump-feature-context.md
# Skip auto-sync if cache is already fresh
code-rcl dump -r App --no-sync
```
### `dump` Options
| `[PATH]` | - | `.` | Target project directory path to scan |
| `-o, --output <PATH>` | `-o` | `codebase-context.md` | Path or name of output Markdown file (auto-appends `.md` if omitted) |
| `--max-size-kb <N>` | - | `50` | Maximum file size (in KB) for content extraction |
| `-r, --relation <NAME>` | `-r` | `None` | Restrict dump to the target symbol/file and its connected dependency graph |
| `--depth <N>` | - | `2` | BFS traversal depth when using `--relation` |
| `--no-sync` | - | `false` | Do not re-sync graph cache before building targeted relation dump |
### Output Markdown Structure
````markdown
> **Targeted dump**: focused on `build_graph` with depth 2.
# Directory Tree
```text
├── Cargo.toml
└── src
├── cli.rs
├── commands
│ └── graph.rs
└── main.rs
```
---
# Source Files
## File: `src/commands/graph.rs`
```rs
// Extracted source code with dynamic fence backtick handling...
```
````
---
## Usage — Code Relation Graph (`init`, `sync`, `graph`, `serve`)
### Quick Setup
```bash
# 1. Initialize .code-rcl/ in your project (creates cache.db and config.toml)
code-rcl init
# 2. Parse source files into cache (Blake3-based incremental indexing)
code-rcl sync
```
### `code-rcl graph` (File Output)
Generates static graph visualizations in standalone HTML, DOT, or JSON format:
```bash
# Default: auto-syncs and outputs .code-rcl/code-graph.html
code-rcl graph
# Generate HTML, JSON, and DOT files simultaneously
code-rcl graph --format html,json,dot -o build/graph
# File-level dependency graph only (imports between files)
code-rcl graph --scope file --min-confidence 0.7
# Focus on a specific symbol and its immediate neighborhood
code-rcl graph --focus App --depth 2
# Limit graph nodes to prevent cluttered views
code-rcl graph --max-nodes 2000
```
#### `graph` Options
| `--project <PATH>` | `.` | Project directory (cache stored in `<project>/.code-rcl/`) |
| `--format <LIST>` | `html` | Comma-separated output formats: `html`, `json`, `dot` |
| `-o, --output <PATH>` | `.code-rcl/code-graph.<ext>` | Output file or path stem when requesting multiple formats |
| `--scope <MODE>` | `both` | Graph scope: `file` (imports only), `symbol`, or `both` (layered) |
| `--kinds <LIST>` | `imports,calls,contains` | Edge kinds to include (`imports`, `calls`, `contains`, `references`) |
| `--path <GLOB>` | `None` | Filter source files by glob pattern |
| `--focus <NAME>` | `None` | Restrict graph to the neighborhood of a symbol or file |
| `--depth <N>` | `2` | BFS traversal depth around `--focus` |
| `--min-confidence <F>` | `0.4` | Filter out resolved edges below this confidence score `[0.0 - 1.0]` |
| `--include-external` | `false` | Include external dependencies (npm, PyPI, crates.io packages) |
| `--max-nodes <N>` | `4000` | Node cap; drops lowest-degree symbols if exceeded (`0` to disable) |
| `--no-sync` | `false` | Render directly from cache without checking/re-parsing modified files |
| `--precise` | `false` | Resolve calls through real language servers ([see below](#compiler-grade-accuracy---precise)) |
---
### `code-rcl serve` (Interactive Browser Viewer)
`code-rcl serve` resolves the graph and hosts an interactive UI on a local HTTP server (`127.0.0.1`), automatically opening your default browser.
```bash
# Build, sync, and launch the interactive viewer on a free port
code-rcl serve
# Pin port and do not launch browser automatically
code-rcl serve --port 8080 --no-open
# Apply filters directly when serving
code-rcl serve --scope symbol --focus handle_request --depth 3
```
#### How `serve` Works
- **Self-Terminating / Zero Background Leak:** An active browser tab maintains an `EventSource` connection (`/live`). Closing the browser tab drops the connection, causing the server to cleanly exit within 2 seconds.
- **Ctrl-C:** Instantly halts the server.
- **No External Network Dependencies:** D3.js and frontend styles are bundled inside the binary; no external CDNs or network connections are made.
#### Browser UI Features
- **Force Simulation:** Real-time physics layout with smooth zooming, panning, and node dragging.
- **Dynamic Filtering:** Checkbox controls for `imports`, `calls`, and `references`.
- **Search & Isolate:** Real-time search bar with instant node filtering and single-click node isolation.
- **Live Depth Controls:** Adjust BFS depth (`+` / `-`) directly from the browser navigation bar.
- **Node Spotlighting:** Long-press any node to spotlight its immediate connections while dimming the rest of the graph.
---
## Usage — `digest` (Architecture Outline & Public API Digest)
Generate a high-level architectural skeleton and public API index. `digest` strips function bodies (`{ ... }`), preserving types, interfaces, methods, and exported signatures to save 80–90% prompt tokens while giving LLMs full structural visibility. It also detects **Core Architecture Hubs** (the highest-degree connected symbols) to highlight the central pillars of the codebase.
### Examples
```bash
# 1. Generate architecture digest for current project to stdout
code-rcl digest
# 2. Save digest to a markdown file (-o / --output, alias: -f)
code-rcl digest -o architecture.md
# 3. Digest a specific sub-directory or sub-module
code-rcl digest src/analysis
# 4. Include private and internal symbols
code-rcl digest --all
# 5. Output structured JSON for automated tooling
code-rcl digest --json
```
### `digest` Options
| `[PATH]` | - | `.` | Target project directory or sub-path to outline |
| `-o, --output <PATH>` | `-o` | *stdout* | Output file path for the generated markdown digest |
| `--all` | - | `false` | Include private/internal functions and types (default: public only) |
| `--json` | - | `false` | Output result as structured JSON instead of Markdown |
| `--no-sync` | - | `false` | Skip auto-syncing changed files before generating digest |
---
## Usage — `impact` (Blast Radius & Impact Analysis)
Analyze the blast radius of modifying a function, class, or module. `impact` performs reverse dependency traversal (`calls` and `imports`) on the relation graph to show every symbol and file that will be affected by your change.
### Examples
```bash
# 1. Inspect who calls or imports `decorate` (terminal ASCII tree)
code-rcl impact decorate
# 2. Increase search depth to 3 hops
code-rcl impact decorate --depth 3
# 3. Output as structured JSON for CI/CD or PR review
code-rcl impact decorate --json
```
### Example Terminal Output
```text
Impact Analysis for: decorate [function]
decorate (util.rs)
└── greet [calls] - function (util.rs:2)
└── main [calls] - function (main.rs:4)
```
### `impact` Options
| `<TARGET>` | - | *required* | Target symbol name or file path to analyze |
| `--project <PATH>` | - | `.` | Target project directory |
| `--depth <N>` | - | `2` | Max reverse traversal depth (hop count) |
| `--kinds <KINDS>` | - | `calls,imports` | Edge kinds to traverse in reverse, comma-separated |
| `--json` | - | `false` | Output result as JSON instead of ASCII tree |
| `--no-sync` | - | `false` | Skip auto-syncing changed files before analyzing |
---
## Language Support
| **Rust** | `.rs` | Tree-sitter | Functions, structs, enums, traits, methods, macros, `use` imports, calls |
| **JavaScript** | `.js`, `.mjs`, `.cjs` | Tree-sitter | Functions, classes, methods, ESM/CJS imports, calls |
| **JSX** | `.jsx` | Tree-sitter | Components, functions, hooks, imports, JSX references |
| **TypeScript** | `.ts`, `.mts`, `.cts` | Tree-sitter | Interfaces, types, classes, functions, modules, imports |
| **TSX** | `.tsx` | Tree-sitter | TS types, React components, hooks, imports, calls |
| **Python** | `.py`, `.pyi` | Tree-sitter | Functions, classes, methods, `import` / `from ... import`, calls |
| **Java** | `.java` | Tree-sitter | Classes, interfaces, enums, records, methods, `import` (incl. `static` / `.*`), calls |
| **Kotlin** | `.kt`, `.kts` | Tree-sitter | Classes, objects, top-level & member functions (incl. `@Composable`), properties, `import` (incl. `as` / `.*`), calls |
| **Go** | `.go` | Tree-sitter | Functions, methods (with receiver types), structs, interfaces, type aliases, `import`, calls |
| **Vue** | `.vue` | SFC Extractor + TS/JS | `<script>` & `<script setup>` symbols, imports, components |
| **Svelte** | `.svelte` | SFC Extractor + TS/JS | `<script>` symbols, imports, reactive calls |
## Resolution Semantics, Accuracy & Limitations
`code-rcl` implements a tiered reference resolver. By default, it runs a fast AST-based heuristic engine that requires no compilation or external toolchain. For exact resolution, `--precise` integrates Language Server Protocol (LSP) backends to compute compiler-grade definitions.
### Resolution Pipeline (L0 – L4)
References are resolved through a 5-tier pipeline ordered by confidence:
1. **L0 — Compiler Backend (`--precise`):** Queries language servers (`rust-analyzer`, `pyright`, `typescript-language-server`, `jdtls`, etc.) via JSON-RPC (`confidence = 1.0`). References resolving to external packages or standard libraries produce no edge, preventing false cross-file links.
2. **L1 — Lexical Scope:** Resolves same-file definitions during the AST walk (`confidence = 0.95`). Identifiers bound to local variables, parameters, or closures are tagged `local_only = true` and quarantined from cross-file matching.
3. **L2 — Explicit Imports & Namespaces:** Resolves qualified paths (`module::func()`) and explicit symbol imports (`use crate::worker::Retry`) (`confidence = 0.90`).
4. **L3 — Receiver Type Deduction:** Resolves calls on `self`, `this`, `Type::method`, and struct field access chains (`self.worker.run()`) against the project's indexed type definitions (`confidence = 0.80 - 0.90`).
5. **L4 — Scored Disambiguation:** Fallback when the receiver type is unannotated or absent from local definitions. Candidates sharing the callee name are scored by import reachability (+3), export visibility (+2), parameter arity match (+1 to +2), and directory proximity (+1). To prevent false positives, an edge is emitted only if the score margin between the top candidate and runner-up is at least 2 (`margin >= 2`). Exact ties emit no edge.
```mermaid
flowchart TD
Ref(["Call Site Reference"]) --> L0{"L0: Language Server?<br/><i>(precise_status)</i>"}
%% L0 Tier
L0 -->|"hit"| Res0["Emit Edge: Target Symbol<br/><b>confidence: 1.00</b>"]
L0 -->|"external / nonode"| Drop0["Drop Edge: External / Stdlib<br/><i>(suppress heuristic false edges)</i>"]
L0 -->|"unresolved / disabled"| L1{"L1: Lexical Scope?<br/><i>(sync-time AST analysis)</i>"}
%% L1 Tier
L1 -->|"local_only = true"| Drop1["Drop Edge: Local Scope Binding<br/><i>(variable, param, closure quarantined)</i>"]
L1 -->|"resolved_symbol_id"| Res1["Emit Edge: Local Symbol<br/><b>confidence: 0.95</b>"]
L1 -->|"unresolved"| L2{"L2: Explicit Import?<br/><i>(binding)</i>"}
%% L2 Tier
L2 -->|"Target::Symbol (named import)"| Res2A["Emit Edge: Import Target<br/><b>confidence: 0.90</b>"]
L2 -->|"Target::Module (module::func / ns.func)"| Res2B["Emit Edge: Module Symbol<br/><b>confidence: 0.90</b>"]
L2 -->|"unresolved"| L3{"L3: Receiver Type?<br/><i>(self, Type::method, self.field)</i>"}
%% L3 Tier
L3 -->|"method found in type_methods"| Res3["Emit Edge: Type Method<br/><b>confidence: 0.80 - 0.90</b>"]
L3 -->|"unresolved"| L4{"L4: Compatible Candidates?<br/><i>(defs_by_name)</i>"}
%% L4 Tier
L4 -->|"no candidates"| Drop4A["Drop Edge: Unknown Symbol"]
L4 -->|"scored candidates"| L4Margin{"Score Margin?<br/><i>(best - runner_up)</i>"}
L4Margin -->|"margin >= 2 or single candidate"| Res4["Emit Edge: Scored Winner<br/><b>confidence: 0.40 - 0.70</b>"]
L4Margin -->|"margin < 2 (ambiguous / tie)"| Drop4B["Drop Edge: Ambiguous Tie"]
%% Styling
classDef success fill:#e1f5fe,stroke:#0288d1,stroke-width:2px,color:#01579b;
classDef drop fill:#efebe9,stroke:#8d6e63,stroke-width:1.5px,stroke-dasharray: 4 3,color:#4e342e;
classDef decision fill:#fffde7,stroke:#fbc02d,stroke-width:2px,color:#f57f17;
class Res0,Res1,Res2A,Res2B,Res3,Res4 success;
class Drop0,Drop1,Drop4A,Drop4B drop;
class L0,L1,L2,L3,L4,L4Margin decision;
```
### Empirical Verification & Accuracy Benchmarks
Resolver behavior is verified by integration test suites in `tests/resolve_accuracy.rs`. Every fixture is an executable program instrumented to verify runtime execution traces (`cargo run`), paired with database assertions on cache tables (`refs.precise_status`, `refs.local_only`):
| `resolve_app` | Cross-file method & bare module path | **100%** / **100%** | *N/A* | Resolved via L2 imports and L3 receiver fields. |
| `local_shadow_app` | Local closure shadowing same-named function | **100%** / **100%** | *N/A* | L1 marks closure call `local_only`, avoiding false cross-file edge. |
| `rust_precise_app` | Inferred constructor return (`let h = Real::new()`) | 80% / 80% | **100%** / **100%** | Heuristics resolve to imported decoy; `--precise` infers return type. |
| `python_precise_app` | Dynamic method polymorphism | 75% / 75% | **100%** / **100%** | Heuristic misses unannotated instance; Pyright resolves runtime class. |
| `generic_type_app` | Standard library `Vec<T>::push` vs custom `push` | 100% / 67% | **100%** / **100%** | Heuristics match single workspace `push`; `--precise` marks `Vec` call external. |
### Known Limitations
- **Standard Library Method Collisions (Heuristic Mode):** Heuristic mode indexes only files within the workspace. When calling common methods (`push`, `len`, `get`) on standard library types (`Vec`, `HashMap`, `Option`), L3 cannot deduce external receiver types and delegates to L4. If only one method with that name exists in the workspace, L4 scores it as an uncontested candidate. Use `--precise` to suppress external library calls.
- **Generic Type AST Normalization:** `impl<T> Buffer<T>` is indexed with its generic parameters. When called from a site typed as `Buffer<String>`, string-equality checks in L3 may fail to pair the receiver, deferring resolution to L4.
- **Dynamic Language Metaprogramming:** Dynamic dispatch (`getattr`, monkey patching, runtime decorators, eval) cannot be resolved statically from AST alone.
- **Build System Prerequisites for `--precise`:** Compiler-grade backends require valid project manifests (`Cargo.toml`, `tsconfig.json`, `pom.xml`, `build.gradle`). Without a project model, language servers degrade to syntax-only inspection.
---
## Compiler-Grade Accuracy (`--precise`)
When exact call resolution is critical, `--precise` queries the real language server for each language where a name is defined, and stores that answer as the top resolution layer (L0):
```bash
# Resolve through installed language servers
code-rcl sync --precise
# Only one language, with custom timeout
code-rcl sync --precise --language rust --precise-timeout 30
# Re-ask about every file (edits can change how other files resolve)
code-rcl sync --precise --precise-full
# Export graph with compiler precision
code-rcl graph --precise
```
### Supported Language Servers
Nothing is bundled. Install the servers for your languages; a missing server is reported with its install command and that language simply retains its heuristic edges.
| **Rust** | `rust-analyzer` | `rustup component add rust-analyzer` | `CODE_RCL_LSP_RUST` |
| **Python** | `pyright-langserver` | `npm install -g pyright` | `CODE_RCL_LSP_PYTHON` |
| **TypeScript** | `typescript-language-server` | `npm install -g typescript-language-server typescript` | `CODE_RCL_LSP_TYPESCRIPT` |
| **JavaScript** | `typescript-language-server` | `npm install -g typescript-language-server typescript` | `CODE_RCL_LSP_JAVASCRIPT` |
| **Java** | `jdtls` (Eclipse JDT LS) | [eclipse.jdt.ls releases](https://github.com/eclipse-jdtls/eclipse.jdt.ls) (needs JDK 17+) | `CODE_RCL_LSP_JAVA` |
| **Kotlin** | `kotlin-language-server` | [kotlin-language-server releases](https://github.com/fwcd/kotlin-language-server/releases) | `CODE_RCL_LSP_KOTLIN` |
| **Go** | `gopls` | `go install golang.org/x/tools/gopls@latest` | `CODE_RCL_LSP_GO` |
#### `sync --precise` Options
| `--precise` | `false` | Resolve references through the real language servers |
| `--precise-full` | `false` | Re-ask about every file, not just the ones with no answer yet |
| `--precise-timeout <SECONDS>` | `15` | Budget for a single language-server answer |
---
## JSON Schema (`--format json`, `version: 2`)
When exporting with `code-rcl graph --format json`, the output conforms to this structure:
```jsonc
{
"version": 2,
"root": "/path/to/project",
"generated_at": 1730000000,
"nodes": [
{
"id": "file:src/main.rs",
"kind": "file",
"label": "src/main.rs",
"path": "src/main.rs",
"dir": "src",
"language": "rust",
"exported": true,
"degree": 3
},
{
"id": "sym:src/main.rs#main@10",
"kind": "function",
"label": "main",
"path": "src/main.rs",
"dir": "src",
"language": "rust",
"exported": false,
"degree": 2
}
],
"edges": [
{
"source": "file:src/main.rs",
"target": "file:src/cli.rs",
"kind": "imports",
"confidence": 1.0
},
{
"source": "sym:src/main.rs#main@10",
"target": "sym:src/commands/dump.rs#run@10",
"kind": "calls",
"confidence": 0.85
}
]
}
```
---
## Model Context Protocol (MCP) Server
`code-rcl` includes a built-in MCP server that runs over standard I/O (`stdio`), allowing AI coding agents (Claude Desktop, Cursor, Gemini Antigravity, Cline, etc.) to perform AST-based architecture discovery and dependency traversal automatically:
```bash
# Launch MCP server over stdio for current directory
code-rcl mcp
# Launch with an explicit target project
code-rcl mcp --project /path/to/project
```
### Instant Automated Setup (`code-rcl setup`)
Instead of configuring JSON files manually, `code-rcl` can self-install its agent skill and register itself into your agent's MCP configuration automatically:
```bash
# Auto-configure current workspace (.agents/skills/code-rcl/SKILL.md and .mcp.json)
code-rcl setup --workspace
# Configure globally for all projects (~/.gemini/config and ~/.claude.json)
code-rcl setup --global
# Target specific agent environments
code-rcl setup --target claude
code-rcl setup --target gemini
# Inspect the embedded skill directly in terminal without writing files
code-rcl setup --print-skill
```
### Manual IDE & Agent Configuration
Alternatively, you can manually add `code-rcl` to your agent's MCP configuration (`mcp_config.json` or `.mcp.json`):
```json
{
"mcpServers": {
"code-rcl": {
"command": "code-rcl",
"args": ["mcp"]
}
}
}
```
### Exposed MCP Tools
1. **`code_rcl_digest`**: Generates a high-level architecture skeleton and public API index with Core Architecture Hubs (strips function bodies to save 80–90% prompt tokens).
2. **`code_rcl_search`**: Instant symbol & declaration lookup across the codebase from the SQLite cache (0–5ms, no grep overhead).
3. **`code_rcl_impact`**: Analyzes reverse caller hierarchy and modification blast radius before editing symbols (supports optional `precise: true`).
4. **`code_rcl_dump`**: Extracts a relation-aware neighborhood context bundle around a focal symbol or file.
5. **`code_rcl_sync`**: Incremental AST sync with optional compiler-grade (`precise: true`) LSP pass for ground-truth verification.
6. **`code_rcl_graph`**: Returns raw nodes and edges of the code graph in structured JSON.
---
## Configuration (`config.toml`)
Running `code-rcl init` creates `.code-rcl/config.toml` in your project root:
```toml
# code-rcl project configuration
schema_version = 1
[sync]
# Skip source files larger than this many KB
max_file_kb = 512
# Languages to analyze
languages = ["rust", "javascript", "typescript", "python"]
[graph]
# Drop resolved edges below this confidence
min_confidence = 0.4
# Include edges to external (npm / pypi / crate) modules
include_external = false
```
---
## License
This project is licensed under the [MIT License](LICENSE).
